Industrial Machinery Brake

Rated 5.00 out of 5 based on 1 customer rating
(1 customer review)

(Motor Starter + Anti-Restart + Motor Braking)

A ready to install safety system for industrial machinery that provides an ANSI-compliant emergency stop, motor braking, and accidental restart protection.

Need another configuration? Want to buy with terms? Want to explore quantity discounts? Request a quote!

Clear
SKU: N/A Category: Safety Systems Tags: QTY Discount, System Bundles
  • Description
  • Specifications
  • Model Number Guide
  • Documents & Downloads
  • Media
  • Reviews (1)

Description

Product Details:

This industrial motor control provides all of the following protections:

  • Motor Braking
  • Anti-Restart
  • Motor Overload Protection
  • Short Circuit Protection
  • Emergency Stop (E-Stop)
  • Visual Status Indication

Our devices also:

  • Come Pre-wired for Easy Installation
  • Fully Approved Industrial Motor Controls (UL 508A)
  • Fully customizable (contact us)

Applications

MAKESafe Industrial Motor Controls can be used with any piece of industrial machinery but the most common applications are on standard machine tools like band saws, surface grinders, bench grinders.

Video Demos

(these videos show another model, but the function is exactly the same as this one)


Each standard package includes:

  • Industrial Machinery Brake and Motor Controller
  • 3-Button Control Panel on 5′ remote tether
  • Product Manual & Adjustment Tool

Need another configuration? Want to buy with terms? Request a quote!

Button Panel Details:

The compact control panels are made of durable ABS plastic and maintains a UL94 V-0 rating. The start and stop buttons are custom manufactured by OTTO Controls in Illinois and are designed for long-term durability with solid aluminum bezels, a no-slip surface finish, and a strong tactile response. The latching emergency-stop button is Swiss-manufactured by EAO. The entire control panel is water, dust, and oil resistant and rated for millions of on/off cycles.

The control panel connects easily to the power tool brake via an industrial M12 twist connector. The 5 ft (1.5m) cable extension and dual mounting flanges allows the control panel to be mounted easily in a convenient location.

Approvals

UL508A: Industrial Control Panels
CSA: Industrial Control Equipment

Alternate Configurations

Our products are also offered with multiple configuration options and accessories, including:

Control Accessories: foot switches, additional e-stop buttons, guard interlocks, attachments for automation

Frequency: products can also be configured for 50hz operation

Plugs: products can be fitted at the factory with any plug type you require

If you want to explore these alternate configurations, please give us a call.

Specifications

Compatibility Guide: see product manual.

Need another configuration? Different plugs? Different Controls? Maybe an international version? Or, do you want to buy with terms? Request a quote!

Model Number PrefixCCP-V240-P3CCP-V480-P3CCP-V600-P3
Rated Input Voltage240VAC 3 PH, 60 Hz (50 Hz options available) 480VAC 3 PH, 60 Hz (50 Hz options available) 600VAC 3 PH, 60 Hz (50 Hz options available)
Rated Horsepower (UL508A)see model number suffix:    HP1 = 1.0 HP    |    HP5 = 5.0 HP    |    HP10 = 10.0 HP
Approvals
UL508A: Industrial Control Panels
CSA #14-13: Industrial Control Equipment
Power ConnectionsProvided with 6′ SO cord on power input and power output.
(NEMA power connectors also available)
Dimensions15.25″ x 13.25″ x 7.75″ (388 mm x 337 mm x 197 mm)
WeightApprox. 35 lbs. (16 kg)

Model Number Guide

IMB
1
-
V240
-
2
P3
-
HP5
3
-

4

1. Product Family

PTC: Power Tool Control

2. Voltage

V120 - P1: 1ϕ 120V
V240 - P1: 1ϕ 240V
V240 - P3: 3ϕ 240V
V480 - P3: 3ϕ 480V
V600 - P3: 3ϕ 600V

3. Horsepower Rating

HP3  : 3.0 HP
HP5  : 5.0 HP
HP7  : 7.5 HP
HP10: 10  HP
HP15: 15  HP
HP20: 20  HP
HP25: 25  HP

4. Configuration Code

(blank)   : Standard 3-Button Control
FS1        : Foot Switch
INT        : 3-Button Control w/ Interlock
FS1-INT: Foot Switch w/ Interlock
C            : Control Pigtail

Documents & Downloads

Dimensional Drawings: Contact Us

CAD Files: Contact Us

Media

Video Demos

1 review for Industrial Machinery Brake

  1. Rated 5 out of 5

    Collins Aero – July 27, 2022

    We’ve been using the smaller MAKESafe units for years and it is great to now have an option for our larger band saws and 480V drill presses. Works perfectly.
