3-Button Control Panel w/ Interlock

Description

Applications:

• Integrating physical guards and interlocks.
• Integrating access control (like a physical key switch or card reader).
• Integrating additional emergency stop buttons.
• Customization.

Interlock Pigtail:

This control panel comes pre-wired with a 5′ pigtail for easy integration into existing interlocks, access control systems, or other controls. Simply connect these two wires to any normally-closed contact or switch. If that contact is open, your machine will not start. If that contact opens while your machine is running, the machine will immediately brake and power off.

3-Button Control Panel Details:

The compact control panels are made of durable ABS plastic and maintains a UL94 V-0 rating. The start and stop buttons are custom manufactured by OTTO Controls in Illinois and are designed for long-term durability with solid aluminum bezels, a no-slip surface finish, and a strong tactile response. The latching emergency-stop button is Swiss-manufactured by EAO. The entire control panel is water, dust, and oil resistant and rated for millions of on/off cycles.

The control panel connects easily to the power tool brake via an industrial M12 twist connector. The 5 ft (1.5m) cable extension and dual mounting flanges allows the control panel to be mounted easily in a convenient location.
